UL Outdoor/Indoor Matte Gray Polyester Permanent Adhesive Label
#102260 - UL Matte Permanent Polyester Label
This 2.0 mil gray polyester with an acrylic permanent self adhesive is a UL Recognized Component under the Category of Marking and Labeling Systems printing materials. The Facestock is Matte top coated gray and resists degradation from scuffing, chemicals, and wide temperature fluctuations. The self adhesive bonds to high and low energy plastic surfaces and slightly oily metals. The adhesive is a clear acrylic, has excellent resistance to chemicals even at high temperatures, and is adaptable to many surfaces with a minimum application temperature of 50°F and a service range -40°F to 302°F. Prints well with color or black and white laser printers.
UL File TEOU2.E243761
|Sheet Ct.||Price Per Sheet|
|8.5″ × 11″||8.5″ × 14″||8.5″ × 17″||11″ × 17″||12″ × 18″||13″ × 19″|
Now available for Wide Format Lasers in the following sizes: 11″ × 17″, 12″ × 18″, 19″ × 22″ up to 36″ long!
|Sheet Ct.||Price Per Sheet|
|8.5″ × 11″|
Let us print for you! Full Color Printing available.
|Thickness (without liner/adhesive):||2.7 mil|
|Temperature Resistance:||-40°F to 302°F|
|Minimum Application Temperature:||50°F|
This is a matte top-coated computer printable gray polyester film coated with a permanent pressure sensitive acrylic adhesive and backed with a backside-printable two-sided poly coated tissue backed easy-release liner. This product is UL approved printing materials - Component when used with certain printer/toner combinations. It is recognized for indoor/outdoor use with occasional exposure to lubricating oil and water.
- Polyester top-coated for excellent anchorage
- Caliper: 2.7 mils
- Dimensional Stability: 100%
- Clear acrylic permanent
- Caliper: 0.8-0.9 mils
- Min. Application Temperature: 50°F
- Indirect Food Contact: No
- Min. Service Temperature: -40°F
- Direct Food Contact: No
- Max Service Temperature: 302°F
- UL Approved: Yes
Note: For best bonding conditions, application surface should be at room temper-ature or higher. Low temperature surfaces, below 50°F can cause the adhesive to become so firm that it will not develop maximum contact with the substrate. Higher initial bonds can be achieved through increased rubdown pressure. In order to get a true measure of the adhesive's effectiveness, the label should be applied and allowed to bond a minimum of 24 hours prior to evaluation.
- Clay coated Kraft (lay-flat) liner which has been silicone coated one side to give a controlled release
- Caliper:5.6 mils
The above are typical technical values and are given in good faith based upon our most up to date knowledge and experience. As the products are used outside our control we cannot take responsibility for any damage that may be caused using the product. In every case, user shall determine before using any product in full-scale production, or in any way, whether such product is suitable for user's intended use for their particular purpose under their own operating conditions.
Technical Specifications for Underwriters Laboratory Users
Rippedsheets.com is Recognized under the Component Recognition Program of Underwriters Laboratory under file E234761, Under the Category of TEOU2, (Repackaged Program).
PN 102260 prints well in any color or B/W laser printer with a label setting. Here are the specific printers approved for UL certification:
|UL Approved Printer|
Make & Model
|HP Laser Jet 4L/ML, 4P/M||92274A|
|HP Laser Jet IIP/IIP Plus and IIIP||92275A|
|HP LJ IIISI/IIISI MX and 4SI/4SI MX||92291A|
|HP LJ II/IID and III/IIID||92295A|
|HP LJ 4/5 Series||92298A|
|HP LJ 4V and 4MV||C3900A|
|HP 4, 4M, 4+, 4M+, 5, 5M, 5N||C3973A|
|HP LJ 5P/MP and 6P/MP||C3903A|
|HP Laser Jet 5SI and 8000||C3909A|
|HP LaserJet 1100 and 1100A||C4092A|
|HP Laser Jet 3100, 3100xi , 3100se||C3906A|
|HP LaserJet 2100 Series||C4096A|
|HP LaserJet 4000, 4050||C4127A|
|HP LaserJet 4000, 4050, and 4100||C8061A|
|HP LaserJet 8150 Series||C4182X|
The B/W laser printer/laser toner combinations and pressure sensitive label has been Recognized under the Component Recognition Program by UL for Printing Materials.
|When Label is affixed to:||Minimum|
|aluminum||-40°C (-40°F)||150°C (302°F)|
|galvanized steel||-40°C (-40°F)||150°C (302°F)|
|alkyd base enamel||-40°C (-40°F)||150°C (302°F)|
|stainless steel||-29°C (-20°F)||150°C (302°F)|
|polyester paint||-29°C (-20°F)||125°C (257°F)|
|porcelain||-40°C (-40°F)||100°C (212°F)|
|melamine plastic||-29°C (-20°F)||100°C (212°F)|
|polycarbonate||-29°C (-20°F)||100°C (212°F)|
|phenolic||-29°C (-20°F)||100°C (212°F)|
|polystyrene||-29°C (-20°F)||80°C (176°F)|
|acrylonitrile butadiene styrene (ABS) plastic||-40°C (-40°F)||80°C (176°F)|
|unsaturated (Thermoset) polyester plastic||-40°C (-40°F)||80°C (176°F)|
|polypropylene plastic||-||80°C (176°F)|
Suitable where exposed indoors to high humidity or occasional exposure to water or lubricating oils. Also suitable where exposed outdoors affixed to aluminum, porcelain, galvanized steel, alkyd enamel, acrylic paint, stainless steel, polyester paint, nylon, melamine plastic, polycarbonate, phenolic, polystyrene, ABS plastic and unsaturated (Thermoset) polyester plastic.
UL File TEOU2.E243761
3 Year Outdoor Test Results
- Coalition of Northeastern Governors (CONEG) Compliant
- Consumer Product Safety Improvement Act (CPSIA) Compliant
- Registration Evaluation Authorization & Restriction of Chemicals (REACH) Compliant
- Restriction of Hazardous Substances (RoHS) Compliant
- Waste Electrical & Electronic Equipment (WEEE) Compliant
- Underwriters Laboratories (UL) Compliant
This product is stocked and can be shipped in as little as 24 hours. Please Contact Us for more information.
