UL Outdoor/Indoor White Polyester Labels
#102250 - UL Matte Permanent Polyester
This 2.3 mil white polyester 3M label with a 1.1 mil acrylic permanent self adhesive are UL approved printing materials - Component and British Standard 5609. The Facestock is radiant white and resists degradation from scuffing, chemicals, and wide temperature fluctuations. Prints extremely well in color and black and white laser printers (For HP: Tuff Setting). Available in 8.5″ × 11″, 11″ × 17″, 12″ × 18″, and 13″ × 19″.
The self adhesive bonds to high and low energy plastic surfaces, textured, and contoured surfaces, powder coatings including textured powder coatings, and slightly oily metals. The adhesive is a clear acrylic, has an excellent resistance to chemicals even at high temperatures, and is adaptable to many surfaces with a minimum application temperature of 50°F and a service range -40°F to 302°F.
UL File TEOU2.E243761
For UL approved printers, click link below. If your printer does not appear on UL list, consult your UL representative. This material contains no halogen and as much as 150 ppm of clorine in the liner material (not in the label Facestock).
|Sheet Ct.||Price Per Sheet|
|8.5″ × 11″||8.5″ × 14″||8.5″ × 17″|
|Sheet Ct.||Price Per Sheet|
|8.5″ × 11″||8.5″ × 14″||8.5″ × 17″||11″ × 17″||12″ × 18″||13″ × 19″|
|5000||$1.12||$1.33||$1.66||Please Contact Us for
Pricing and Availability
Let us print for you! Full Color Printing available.
|Thickness (without liner/adhesive):||2.3 mil|
|Temperature Resistance:||-40°F to 300°F|
|Minimum Application Temperature:||50°F|
Description:This label features a standard pressure sensitive construction including a 2.3 mil laser-printable matte polyester Facestock that has excellent heat resistance and dimensional stability. This material features an aggressive adhesive that shows good initial tack, high shear strength, and excellent clarity. The clay-coated kraft liner has been coated one side to give a controlled release. This product is a UL approved printing material.
- 2.3 mil white top-coated polyester with a very smooth matte finish. It has excellent tear strength, heat resistance and dimensional stability while the top-coating offers excellent laser toner receptivity.
- Caliper: 2.3 mil
- Opacity: 75%
- Clear acrylic adhesive featuring good removability on a wide range of substrates including corrugated and many plastic surfaces.
- Coat Weight:1.1 cwt
- Min. Application Temperature: 50°F
- Indirect Food Contact: No
- Min. Service Temperature: -40°F
- Direct Food Contact: No
- Max Service Temperature: 300°F
- UL Approved: Yes
Note: For best bonding conditions, application surface should be at room temper-ature or higher. Low temperature surfaces, below 40°F can cause the adhesive to become so firm that it will not develop maximum contact with the substrate. Higher initial bonds can be achieved through increased rubdown pressure. In order to get a true measure of the adhesive's effectiveness, the label should be applied and allowed to bond a minimum of 24 hours prior to evaluation.
- Clay-coated lay-flat liner which has been silicone coated one side to give a controlled release.
- Caliper: 4.6 mils
- Weight: 78#
The above are typical technical values and are given in good faith based upon our most up to date knowledge and experience. As the products are used outside our control we cannot take responsibility for any damage that may be caused using the product. In every case, user shall determine before using any product in full-scale production, or in any way, whether such product is suitable for user's intended use for their particular purpose under their own operating conditions.
Technical Specifications for Underwriters Laboratory Users
102250 Outdoor/Indoor White Polyester Perm
Rippedsheets.com has Underwriters Laboratory authority in UL file TEOU2.E243761 to apply the Repackaged Recognition Marking to repackaged label and tag products.
PN 102250 prints well in any color or B/W laser printer with a label setting. Here are the specific printers approved for UL certification:
|Printer Type||Toner Part #|
|HP Laser Jet 4L/ML, 4P/M||92274A|
|HP Laser Jet IIP/IIP Plus and IIIP||92275A|
|HP LJ IIISI/IIISI MX and 4SI/4SI MX||92291A|
|HP LJ 4/5 Series||92298A|
|HP LJ 4V and 4MV||C3900A|
|HP LJ 5P/MP and 6P/MP||C3903A|
|HP Laser Jet 5SI and 8000||C3909A|
The black and white laser printer/laser toner combinations and pressure ensitive label have been tested by UL and given the following UL certifications:
|Material Adhered to:||Minimum temperature||Maximum temperature|
|Stainless Steel||-40°C (-40°F)||150°C (302°F)|
|Galvanized Steel||-40°C (-40°F)||150°C (302°F)|
|Aluminum||-40°C (-40°F)||150°C (302°F)|
|Alkyd Paint||-40°C (-40°F)||150°C (302°F)|
|Acrylic Paint||-40°C (-40°F)||150°C (302°F)|
|Polyester Paint||-40°C (-40°F)||150°C (302°F)|
|Epoxy Paint||-40°C (-40°F)||150°C (302°F)|
|-40°C (-40°F)||150°C (302°F)|
|Porcelain||-40°C (-40°F)||150°C (302°F)|
|Phenolic||-40°C (-40°F)||100°C (212°F)|
|Nylon||-40°C (-40°F)||100°C (212°F)|
|Polycarbonate||-40°C (-40°F)||100°C (212°F)|
|Polystyrene||-40°C (-40°F)||80°C (176°F)|
|Polyphenylene Oxide||-40°C (-40°F)||80°C (176°F)|
|Polypropylene||-40°C (-40°F)||80°C (176°F)|
|Acrylonitrile Butadiene Styrene|
|-40°C (-40°F)||60°C (140°F)|
Suitable where exposed indoors to high humidity or occasional exposure to water. Also suitable where exposed outdoors to all surfaces except polycarbonate and polypropylene.
CSA approved under CSA Class Number 792201 - Adhesive Type Labels - Label Stock.
|Approved for Indoor/Outdoor use on||Maximum Temperature|
|Plastics Group I||100°C|
II, III, IV, V, VI, VII and VIIII
CSA requires that CSA customers must apply for component acceptance for their marking label printed with their laser printer under Class 7921 - printed labels which takes as little as two weeks according to CSA. CSA customers must contact the CSA Component Acceptance Department after purchasing Rippedsheets.com materials for CSA laser printer testing and acceptance. Rippedsheets.com PN 102280 is already CUL CSA approved for certain laser printers.
- Coalition of Northeastern Governors (CONEG) Compliant
- Consumer Product Safety Improvement Act (CPSIA) Compliant
- Registration Evaluation Authorization & Restriction of Chemicals (REACH) Compliant
- Restriction of Hazardous Substances (RoHS) Compliant
- Waste Electrical & Electronic Equipment (WEEE) Compliant
- Underwriters Laboratories (UL) Compliant
This product is stocked and can be shipped in as little as 24 hours. Please contact us for more information.
